Kode Produk:ARM009
Ketersediaan:Out Of Stock
Harga: Rp.585.000,00


  •     STM32F429ZIT6 microcontroller featuring 2 MB of Flash memory, 256 KB of RAM in an LQFP144 package
  •     On-board ST-LINK/V2 with selection mode switch to use the kit as a standalone
  •     ST-LINK/V2 (with SWD connector for programming and debugging)
  •     Board power supply: through the USB bus or from an external 3 V or 5 V supply voltage
  •     2.4" QVGA TFT LCD
  •     SDRAM 64 Mbits
  •     L3GD20, ST MEMS motion sensor, 3-axis digital output gyroscope
  •     Six LEDs:
  •     LD1 (red/green) for USB communication
  •     LD2 (red) for 3.3 V power-on
  •     Two user LEDs:LD3 (green), LD4 (red)
  •     Two USB OTG LEDs:LD5 (green) VBUS and LD6 (red) OC (over-current)
  •     Two pushbuttons (user and reset)
  •     USB OTG with micro-AB connector
  •     Extension header for LQFP144 I/Os for a quick connection to the prototyping board and an easy probing
